Grinding Segments
| TradeName | Saint-Gobain Abrasives | Abrasive Material | Ceramic Alumina |
| Width | 11-1/4″ | Wheel Type | Type 31 |
| Height | 6″ | Specification | 3NQP36-G12VSP |
| Thickness | 2-1/4″ | Bond Type | VSP |
| Grit | 36 | Type | Surface/Cylindrical Wheels |
| Hardness | G |
Product Features
| Remarks | •Revolutionary, versatile engineered ceramic grain shape and chemistry for maximum productivity; lowest total grinding costs.•The porous VSP vitrified bond increases chip clearance and maximizes coolant flow, reduces loading and is cool cutting in heat-sensitive applications.•For use in Cortland chucks on surface grinding machines.•Best choice for all low, medium, and high-force applications ranging from cast iron, to stainless steel and hard-to-grind alloys.•Performs well on old and new machines with 33 to 100% longer life versus competitive ceramic products; 30%, or better, higher metal removal rate; 15%, or better, lower threshold power.•Surface grinding segments are generally used to grind flat stock or flat surfaces within a workpiece. The segment moves over the workpiece in a flat plane or vice versa. Applications can vary from heavy, rapid stock removal to precision tolerance operations. | Country of Origin | Mexico |
Shipping Info
Additional Fees and Notes
1
Hazard Code
A
Shipping Notes
Additional Charges
Package Weight
2
